Xylem 404200 Float & Thermostatic Steam Trap 3/4" NPT 15 PSI

The Xylem-Hoffman Specialty 404200 FT015H is a Series H float and thermostatic steam trap designed for continuous drainage in low, medium, and high-pressure steam systems. This versatile trap features a 3/4" NPT connection in an H-pattern configuration with cast iron construction and stainless steel internal components for exceptional durability and corrosion resistance.

Key Features:

• 3/4" NPT threaded connections in H-pattern same-side configuration
• Universal 4-port tappings (2 inlets, 2 outlets) for installation flexibility
• Cast iron body with stainless steel internals
• 15 PSI maximum operating pressure (250 PSI maximum allowable pressure)
• Condensate capacity of 1,600 pounds per hour
• Continuous drainage design for reliable operation
• Designed to quickly vent air and non-condensable gases
• Maximum temperature rating of 406°F (208°C)

The H-pattern configuration allows steam to enter from either side of the trap and condensate to discharge from either the opposite or same side, providing exceptional piping flexibility. Ideal for heat exchange equipment, modulating pressure applications, and systems with widely varying loads. The float and thermostatic design ensures efficient condensate removal while preventing steam loss, making it perfect for boiler systems, steam mains, and industrial process applications.
