Carrier HC30CR235 Draft Inducer Motor 1/16 HP 208-230V 3450 RPM

The Carrier HC30CR235 is a genuine OEM draft inducer motor designed for reliable performance in residential and light commercial gas furnaces. This factory-authorized replacement component ensures proper venting operation by creating the negative pressure necessary to safely remove combustion gases through the heat exchanger and out of the system.

Key Specifications:

• Horsepower: 1/16 HP
• Voltage: 208-230V, 60 Hz, Single Phase
• Speed: 3450 RPM
• Amperage: 0.43-0.47 Amps
• Rotation: Clockwise Lead End (CWLE)
• Shaft: 5/16" diameter single side flat shaft
• Frame: Open, thermally protected
• Insulation Class: B
• Bearings: Sealed ball bearings
• Capacitor: 4 MFD @ 370 VAC (included)
• Motor Cooling: Air Over

Features & Benefits:

• Genuine Carrier OEM part manufactured to factory specifications
• Works with Carrier and related brand furnace units
• Thermally protected motor prevents overheating damage
• Sealed ball bearings provide long-lasting, quiet operation
• Includes required capacitor for immediate installation
• Replaces older part number HC30CK235

This inducer motor plays a critical role in the furnace ignition sequence by clearing residual gases before startup and maintaining proper airflow through the heat exchanger during operation. Professional installation is recommended to ensure proper operation and safety.
