Carrier 06EA507202 OPSS Oil Pressure Sensor Block for Carlyle 06D/06E/06CC Compressors

Manufacturer

Part Number

06EA507202
Black Friday Price

$327.38

1 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Carrier 06EA507202 Sensor Block is the OEM oil pressure sensor block designed for use with the Carlyle Oil Pressure Safety Switch (OPSS) system on Carlyle 06D, 06E, and 06CC series semi-hermetic reciprocating compressors. This component mounts directly to the compressor's bearing head and serves as the interface point for the OPSS screw-in sensor, enabling continuous differential oil pressure monitoring to protect the compressor from loss of lubrication.

The sensor block is installed over the sensor block gasket (P/N 06DA504473) and the 1/4" NPT O-ring seal fitting on the high-side oil pump pressure port. It is secured to the bearing head using four 5/16"-18 x 1-1/4" Allen head bolts and houses the OPSS sensor, which connects both the suction and high-pressure sides of the oil pump for differential pressure measurement.

Key Features:

  • OEM Carrier/Carlyle replacement sensor block for 06D, 06E, and 06CC compressor series
  • Required component to support Carlyle Oil Pressure Safety Switch (OPSS) kits
  • Mounts to compressor bearing head via four 5/16"-18 x 1-1/4" Allen head bolts
  • Compatible with 1/4" NPT O-ring seal fitting interface
  • Mounting bolt torque specification: 15–21 ft-lbs
  • OPSS sensor hex nut torque specification: 45–55 ft-lbs
  • Works in conjunction with sensor block gasket P/N 06DA504473 (sold separately)
  • Enables compressor shutdown protection upon detection of low oil differential pressure

The Carlyle OPSS system, which this sensor block supports, serves as an upgrade to legacy Danfoss MP54 and Penn P545 oil pressure safety switches. It protects Carlyle reciprocating compressors with oil pump lubrication from bearing and internal component damage caused by insufficient lubrication. The two-part OPSS design — sensor unit and electronic unit — allows the electronic module to be serviced without opening the refrigerant circuit.
