Carrier RH2BUAC24 DPDT 24VAC General Purpose Power Relay

Manufacturer

Part Number

RH2BUAC24
Black Friday Price

$131.50

1 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Carrier RH2BUAC24 is an OEM general-purpose power relay designed for use in Carrier HVAC control circuits. This compact electromechanical relay features a 24VAC coil and a Double Pole Double Throw (DPDT) contact configuration, making it a versatile switching component for a wide range of heating, cooling, and air handling control applications.

Key Features:

  • Contact Configuration: DPDT (Double Pole Double Throw) — 2 poles, 2 Form C
  • Coil Voltage: 24 VAC (50/60 Hz), with an operating range of 19.2–26.4 VAC
  • Contact Rating: 10A continuous; 10A resistive load at 110 VAC
  • Contact Material: Silver Cadmium Oxide (AgCdO) for reliable, long-life switching
  • Terminal Style: Blade terminals for socket mounting
  • Mounting Options: Compatible with DIN rail, surface, panel, and PCB-type sockets
  • Operate/Release Time: 20ms maximum
  • Insulation Resistance: 100 MΩ minimum (measured at 500 VDC)
  • Operating Temperature: -30°C to +70°C (-22°F to +158°F)
  • Certifications: UL Recognized, CSA Certified, CE Marked, TÜV

This relay is a direct OEM replacement for Carrier furnaces, air handlers, heat pumps, and condensing units requiring a 24VAC DPDT control relay. The compact midget-style form factor and blade terminal design allow for straightforward socket-mount installation in existing Carrier control panels.
