Johnson Controls TE-6350F-0 Wall Plate Room Temperature Sensor 1K Ohm Platinum BACnet

The Johnson Controls TE-6350F-0 is a flush-mount, wall plate room temperature sensor from the TE-6300 Series, featuring a 1,000 ohm platinum sensing element with BACnet compatibility and the Johnson Controls logo. Designed for use in commercial building automation and HVAC control applications, this passive, two-wire, resistance-output device delivers precise and reliable room temperature measurement in a clean, professional profile.

Part of the TE-6300F Series flush-mount sensor family, the TE-6350F-0 mounts over a standard electrical wallplate (80 x 120 mm) and integrates seamlessly with BACnet MS/TP, N2, and Metasys® building automation systems. The platinum sensing element provides a nominal resistance of 1,000 ohms at 32°F (0°C), offering high accuracy and long-term stability.

Key Features:

• Sensing element: 1,000 ohm Platinum (1K Pt)
• Flush-mount wallplate design — fits standard 80 x 120 mm wall box
• Two-wire, passive, resistance-output device
• Compatible with BACnet MS/TP and N2 building automation networks
• Features the Johnson Controls logo for professional installation aesthetics
• Part of the TE-6300 Series — a versatile, economical temperature sensing platform
• Includes necessary mounting accessories for streamlined installation
• Suitable for room/zone temperature sensing in commercial HVAC applications

The TE-6300 Series supports a wide range of sensing applications — including wall-mount, outdoor-air, duct, strap-mount, and well-insertion — making it easy to source all temperature sensing needs from a single product family. The TE-6350F-0 is the BACnet logo variant of the flush-mount platinum sensor; the TE-6350F-1 is the equivalent model without the logo. Reference Johnson Controls Product Bulletin LIT-216320 for full application and installation guidance.
