The Memphis Audio MJP1522 is a 15-inch MOJO Pro Series component subwoofer engineered for high sound pressure level (SPL) performance. Built on the legacy of the acclaimed MOJO Series, the MOJO Pro line takes output capability to the next level with a robust motor structure, advanced cooling technology, and a construction spec sheet designed for listeners who demand serious bass.
At the heart of the MJP1522 is a rigid treated paper cone paired with a double-stitched high-roll foam surround capable of handling extreme excursion without distortion. The vented die-cast aluminum basket provides a rock-solid foundation, while a 2.5-inch high-temperature voice coil and 120 oz. magnet structure deliver the motor force needed to push 750 watts RMS (1,500 watts peak) reliably and cleanly.
Memphis Audio's proprietary DVVC (Direct Vent Voice Coil Cooling) system positions venting directly below the coil, rapidly exhausting trapped heat with every movement of the cone — far more efficiently than traditional pole venting. Cross-drilled front plate venting further reduces compression and keeps temperatures in check during extended high-power sessions. An aluminum shorting ring minimizes inductance for tighter, more accurate low-frequency reproduction at high volumes.
The dual 2-ohm voice coils offer flexible wiring options: wire in parallel for a 1-ohm load, or in series for a 4-ohm load — making this subwoofer adaptable to a wide range of amplifier configurations. A progressive spider provides precise linear control and durability under sustained power, while single-sided compression terminals simplify wiring connections.
Key Features:
- 15" MOJO Pro Series component subwoofer
- Dual 2Ω voice coils — wireable to 1Ω (parallel) or 4Ω (series)
- 750W RMS / 1,500W peak power handling
- 2.5" high-temperature voice coil
- DVVC Direct Vent Voice Coil Cooling technology
- Cross-drilled front plate venting for reduced compression
- Aluminum shorting ring for reduced inductance
- Rigid treated paper cone with double-stitched high-roll foam surround
- Vented die-cast aluminum basket
- Progressive spider for linear excursion control
- 120 oz. magnet | 6.69" magnet diameter
- Single-sided compression terminals
- Frequency response: 30–150 Hz
- Sensitivity: 87 dB
- Mounting depth: 7.88" | Cutout diameter: 13.84"
- Frame outside diameter: 15.9"
- Recommended sealed enclosure: 2.6 cu. ft. (single)
- Recommended ported enclosure: 4.4 cu. ft. (single), tuned to 34 Hz
- UPC: 702588001713
Thiele-Small Parameters:
- Resonant Frequency (fs): 33.6 Hz
- Total Q (Qts): 0.746 | Mechanical Q (Qms): 7.95 | Electrical Q (Qes): 0.823
- Xmax (linear): 0.51 in. (12.95 mm)
- Vas: 2.31 cu. ft. (65.42 L)
- Moving Mass (Mms): 334.4 g
- Motor Strength (Bl): 9.3 T·m
- Effective Piston Area (Sd): 829.58 cm²
The MJP1522 is a purpose-built SPL subwoofer sized to fit traditional enclosures, making it an excellent choice for enthusiasts who want competition-grade bass output without custom-only box requirements.
