The Memphis Audio MJP1244 is a 12-inch MOJO Pro Series component subwoofer engineered from the ground up for high-SPL (Sound Pressure Level) performance. Built on the foundation of the popular MOJO Pro speaker line, this sub is designed to deliver thunderous, hard-hitting bass output in more traditional enclosures—bringing MOJO performance to a wider range of system designs.
At the heart of the MJP1244 is a rigid paper cone paired with a double-stitched foam surround and a heavy-duty die-cast aluminum basket. Memphis Audio's patented DVVC (Direct Vent Voice Coil Cooling) system, combined with cross-drilled front plate venting, keeps the driver running cool under sustained, high-power use. An aluminum shorting ring reduces inductance for cleaner, more linear output at elevated power levels.
The dual 4-ohm voice coil configuration offers installation flexibility—wire the coils in series for an 8-ohm load or in parallel for a 2-ohm load, making it easy to match a wide range of amplifiers. The 2.5-inch voice coil handles up to 750 watts RMS (1,500 watts peak), while single-sided compression terminals simplify wiring connections.
Key Features:
- 12-inch MOJO Pro Series component subwoofer
- Dual 4-ohm voice coils — wires to 2 ohms (parallel) or 8 ohms (series)
- 750W RMS / 1,500W peak power handling
- DVVC Direct Vent Voice Coil Cooling with cross-drilled front plate
- 2.5-inch voice coil diameter
- Rigid paper cone with double-stitched foam surround
- Vented die-cast aluminum basket
- Aluminum shorting ring for reduced inductance
- Progressive spider for controlled excursion
- Single-sided compression terminals
- Sensitivity: 85.68 dB
- Mount depth: 6.23 inches | Cutout diameter: 11.34 inches
Thiele-Small Parameters:
- Resonant Frequency (Fs): 36.7 Hz
- Mechanical Q (Qms): 7.217
- Electrical Q (Qes): 0.764
- Total Q (Qts): 0.69
- Xmax Linear: 0.51 in
- Displacement: 0.16 cf
- Vas: 1.09 cf
- Moving Mass (Mms): 241.3 g
- Suspension Compliance (Cms): 0.078 mm/N
- Effective Piston Area (Sd): 530.93 sq cm
- Motor Strength (Bl): 11.23 T·M
- DC Resistance: 1.73 ohms
- Magnet Weight: 120 oz | Magnet Diameter: 6.6 in
Whether you're building a competition-grade SPL system or simply want authoritative, room-filling bass, the MJP1244 delivers the power, cooling, and cone control to perform at its best—session after session.
