InSize 2307-05 Precision Dial Indicator 0.5" Range .001" Graduation Lug Back

The InSize 2307-05 is a precision dial indicator designed for accurate dimensional measurement in machining, metalworking, and quality control applications. This professional-grade instrument features a 0.5 inch (0-0.500") measuring range with .001" graduation for precise readings, making it ideal for runout measurement, alignment checks, and surface flatness inspection.

Key Specifications:

• Measuring Range: 0-0.500 inches
• Graduation: .001 inch increments
• Accuracy: .002" for first 2.5 revolutions, .003" overall
• Stem Diameter: 3/8 inch (.375")
• Bezel Diameter: 2.36 inches
• Contact Point Thread: #4-48 UNF
• Dial Reading: 0-100 continuous
• Meets DIN878 and ANSI B89.1.10 standards

Features:

• Lug back mounting configuration for secure attachment to magnetic bases and indicator stands
• Aluminum body construction for durability and reduced weight
• Bezel locking clamp for secure dial positioning
• Tolerance index pointers included for quick go/no-go inspection
• Continuous reading dial eliminates counting revolutions
• Supplied in fitted storage case for protection

This dial indicator is compatible with standard magnetic base stands and accepts optional contact points and back attachments for versatile measurement setups. The smooth operation and easy-to-read dial face make it suitable for both professional machine shops and precision manufacturing environments.
