Mitutoyo 201-155 Dial Snap Gage 4-5 Inch Range

The Mitutoyo 201-155 is a precision dial snap gage designed for quick and accurate measurement of external diameters on cylinders, shafts, and other round workpieces in the 4 to 5 inch range. This measuring tool is ideal for production environments where rapid GO/NO-GO inspection is required to maintain tight tolerances in machining processes.

Key Features:

• Measuring range: 4 to 5 inches
• 3/8 inch diameter stem for stable handling and measurement
• Chamfered anvil edges on both front sides for easy insertion and positioning on workpieces
• C-frame design provides open access for quick measurements
• Accepts standard dial indicators (sold separately)
• Hardened and precision-ground anvils for durability and accuracy

Note: Dial indicator is not included and must be purchased separately. This snap gage body is compatible with Mitutoyo dial indicators featuring standard mounting stems.

Mitutoyo snap gages are widely used in manufacturing, quality control, and inspection departments for their reliability and precision. The chamfered anvil design allows for smooth engagement with the workpiece, reducing measurement errors and improving inspection efficiency.
