Spirax Sarco 54751 Float Mechanism Assembly for FT-125 and FTI-125 Steam Traps

Manufacturer

Part Number

54751
Black Friday Price

$343.77

1 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Spirax Sarco 54751 is a precision-engineered float mechanism assembly designed as a replacement component for FT-125 and FTI-125 series float and thermostatic steam traps. This essential internal component enables continuous condensate drainage in steam systems operating at pressures up to 125 PSI.

Key Features:

  • Compatible with FT-125 and FTI-125 steam trap models in 3/4" and 1" sizes
  • Lever and seat operation design for reliable condensate control
  • Stainless steel construction for corrosion resistance and durability
  • Sold without float (float sold separately as part number 55447)
  • Rated for 125 PSI maximum operating pressure applications
  • Direct replacement for worn or damaged mechanisms

How It Works:

The float mechanism uses a lever and seat operation that is secured by threading the seat into the outlet port within the trap body. When attached to a float, the mechanism opens and closes based on condensate levels, allowing efficient drainage while preventing steam loss. As condensate accumulates and the float rises, the lever opens the seat to discharge condensate. When steam is present, the float lowers and closes the seat.

Applications:

This mechanism is used in steam traps serving heat exchangers, process equipment with modulating temperature control, unit heaters, air heating coils, and steam main drip stations. It provides continuous drainage capability for low, medium, and high-pressure steam systems in industrial and commercial applications.

Note: This part includes the mechanism assembly only. The float (part number 55447) and cover gasket (part number 55475) are sold separately and may be required for complete trap repair.
