Fuelab 62813-5 Quick Service Surge Tank Dual Brushless Pumps with Controller Gold - 2.0 500LPH

The Fuelab 62813-5 is a complete Quick Service Surge Tank 2.0 (QSST 2.0) system finished in a gold anodized billet aluminum housing. This fully equipped kit includes a Fuelab 49614 brushless lift pump, dual 500 LPH brushless surge tank pumps, and an integrated PWM fuel pump controller — delivering a complete, high-performance in-cell fuel delivery solution for serious motorsport applications.

Fuelab's QSST 2.0 design revolutionizes surge tank serviceability. With only 10 bolts on the top service cover, the entire pump hanger assembly can be removed and pumps serviced in minutes — without pulling the full 24-bolt base plate or removing the surge tank housing from the fuel cell. This is a significant advantage over traditional designs that require complete teardown for pump access.

Key Features:

• Complete QSST 2.0 system — lift pump, dual surge pumps, and controller included
• Dual 500 LPH brushless surge tank pumps for maximum high-demand flow
• Fuelab 49614 brushless lift pump feeds surge tank from main fuel cell
• Integrated PWM brushless pump controller eliminates need for external controller
• Gold anodized billet aluminum construction for durability and corrosion resistance
• Quick-service top-access design — pump hanger removable with 10 bolts
• Fits industry-standard 24-bolt fuel cell fill plate bolt pattern
• Compatible with gasoline, E85 ethanol, and methanol fuels
• Rollover flap protection and fuel tank vent with rollover protection
• Corrugated fuel hose for lift pump to surge tank connection included
• Gaskets and 1/4 in.-28 hardware for fuel cell nut ring mounting included
• Compatible with brushed or brushless pump combinations via same base plate

The Fuelab QSST 2.0 is engineered for drag racing, road racing, drifting, and high-horsepower street builds where fuel starvation from fuel slosh is a real concern. The dual 500 LPH brushless pump configuration supports extreme power levels. Covered by Fuelab's Forever Fixed lifetime warranty against material and workmanship defects.
