Heil 1013341 Furnace Blower Motor 1/2 HP 115V 4-Speed 1050 RPM

The Heil 1013341 is a genuine OEM furnace blower motor designed for residential HVAC systems. This high-quality replacement motor is manufactured to exact specifications and is compatible with multiple ICP (International Comfort Products) brands including Heil, Tempstar, Comfortmaker, and Arcoaire furnaces and air handlers.

Key Specifications:

• Power: 1/2 horsepower (HP)
• Voltage: 115 volts, 60 Hz, single phase
• Speed: 4-speed motor with 1050 RPM rating
• Rotation: Counter-clockwise (CCW)
• Frame: 48Y frame size with 5 5/8-inch diameter
• Shaft: 4-inch shaft extension
• Amperage: 8 amps
• Capacitor: Requires 7.5 MFD capacitor

Cross-Reference Information:

This motor replaces multiple OEM part numbers including 1009053, 1012513, 1172487, and HQ1013341EM. The equivalent Emerson motor part number is K55HXJEW-9056, and it is also compatible with US Motors specifications.

Designed for direct replacement installation in compatible furnace and air handler units. The motor features standard wire connections matching OEM specifications for straightforward installation by qualified HVAC technicians.
