Johnson Controls BASRTP-B BAS Portable BACnet Router BACnet/IP to MS/TP

The Johnson Controls BASRTP-B BAS Portable Router is a compact BACnet multi-network router designed for commissioning and troubleshooting building automation systems. This versatile device provides stand-alone routing between BACnet/IP, BACnet Ethernet (ISO 8802-3), and BACnet MS/TP networks, making it an essential tool for system integrators and technicians.

Key Features:

• Portable design that's easy to carry to job sites for field commissioning and troubleshooting
• USB-powered operation (5 VDC) - no external power supply needed, draws power directly from laptop USB port
• Web-based configuration interface accessible through any standard browser for easy setup
• 10/100 Mbps Ethernet port with shielded RJ-45 connector featuring auto-negotiation and Auto-MDIX
• Optically-isolated MS/TP port with removable 3-pin terminal block for EIA-485 or RJ-11 connection
• Supports MS/TP baud rates of 9600, 19200, 38400, and 76800 bps
• Built-in diagnostic capabilities with web-based MS/TP device status table and network statistics
• Three LED indicators for power, Ethernet activity (100/10 Mbps), and MS/TP traffic monitoring
• Factory default IP address of 192.168.92.68 with easy reset switch
• Operating temperature range of 32°F to 140°F (0°C to 60°C)

The BASRTP-B includes a resident web server that provides diagnostic web pages with graphical MS/TP device status, network error counts, and BACnet network traffic statistics. The status page automatically refreshes every 5 seconds, allowing real-time monitoring of network conditions. No special Windows drivers are required - simply connect via USB for power and Ethernet for network access. This router is CE marked, RoHS compliant, and meets UL 508 Industrial Control Equipment standards.
