KC HiLiTES 0292 FLEX ERA LED Light Bar Master Kit - 20-Inch

The KC HiLiTES 0292 FLEX ERA LED Light Bar Master Kit is a 20-inch LED light bar for off-road and auxiliary lighting. It succeeds the original FLEX Array light bars. It is built around high-output performance and a flexible design. The Master Kit bundles both beam pattern lenses, so you can choose the beam for your driving conditions.

Key Features:

• 20-inch FLEX ERA LED light bar made of two 10-inch segments. It ships unassembled so you can set it up to suit your needs.
• Segments join with Linker Brackets and Power Linkers. At each linker joint you can set the bar to a straight or radius (curved) configuration.
• Master Kit includes both beam pattern lenses. The Combo Beam lens comes pre-installed and the Spot Beam lens is included for longer-distance visibility.
• Two power modes: an Amber LED backlight, and full high-power white light. Full power is for off-road use only.
• Amber backlight can be used on-road or off-road, day or night.
• Bezels come standard in gold. Deep red, rich blue and gloss black bezels are available separately.
• Aluminum alloy construction.

Specifications:

• Lumens: 15,824 lm at 5000K
• Lux at 10 meters: 3,220 lx (combo) / 3,600 lx (spot)
• Candela: 322,000 cd (combo) / 360,000 cd (spot)
• Wattage: 24W (amber backlight) / 216W (high power)
• Amp draw at 12V: 2.0A / 18.0A
• Voltage: 9V-36V
• IP rating: IP68

What's Included:

• (2) 10-inch KC FLEX ERA LED light bars
• Linker and end mount assembly kit
• Combo beam lens (pre-installed) and spot beam lens
• Light cover, black with yellow KC logo
• Complete plug-and-play wiring harness with dual-throw LED switch
