Forced Performance 2035020A FP8488S 84HTZ UHF 88S Journal Bearing Race Turbocharger

The Forced Performance FP8488S HTZ UHF 88S is a large-frame, journal bearing race turbocharger built for extreme power applications. Featuring an 84mm HTZ compressor wheel machined 100% in the USA, this unit flows 135+ lbs/min, placing it firmly in the 1,200–1,400 HP range — suitable for high pressure ratio small-engine builds and lower pressure ratio V8 applications alike.

Key Specifications:

• Compressor Wheel: 84HTZ — 84mm Inducer / 116mm Exducer
• Flow Rating: 135+ LB per minute
• Turbine Wheel: Ultra High Flow 88S — 96mm Inducer / 88mm Exducer (6+6 blade UHF design)
• Compressor Housing: 42R / S400 Style Cover
• Turbine Housing: S400 96mm Compatible
• CHRA: S400 Oil-Cooled Journal Bearing
• Oil Supply Line Recommendation: -6 AN oil supply line

HTZ Compressor Technology: All rotating assembly components are zero-balanced individually before assembly. The HTZ compressor aero wheels are manufactured entirely in the United States and the completed CHRA undergoes a final balance verification to ensure optimal rotating assembly integrity.

Ultra High Flow 88S Turbine Wheel: Drawing on Xona Rotor-derived technology, the 88S turbine wheel shares the same physical footprint as the proven BW 96/88mm turbine wheel while delivering significantly increased choke flow capacity — without sacrificing spool characteristics.

All Forced Performance turbochargers are built to order. This product is for competition use only. Use for highway or non-competition off-road purposes is contrary to federal law.
