Schneider Electric MN-SDK MicroNet Digital Room Temperature Sensor with 4-Button Keypad and Display

The Schneider Electric MN-SDK is a microprocessor-based digital room temperature sensor designed for precise environmental monitoring and control in commercial and industrial HVAC applications. This deluxe model features a large, easy-to-read liquid crystal display and a 4-button keypad that allows users to view and adjust controller settings directly at the wall-mounted unit.

Key Features:

• Microprocessor-based digital temperature sensing with precision thermistor technology
• Large LCD display for clear temperature readout and system status
• Four-button keypad for local control and setpoint adjustment
• Operating temperature range: 32°F to 122°F (0°C to 50°C)
• Humidity tolerance: 5% to 95% RH, non-condensing
• NEMA-1 rated enclosure for reliable protection
• U-Link communication interface connects to MicroNet 2000 family controllers
• Plug-in communication jack for PC interface and programming
• Contemporary low-profile design suitable for direct-wall or electrical box mounting
• Compatible with MicroNet VAV controllers and building management systems

The MN-SDK sensor communicates with MicroNet controllers via a simple two-wire U-Link interface that provides both power and data transmission. The integrated keypad allows facility operators to override unoccupied mode settings, adjust temperature setpoints, and scroll through controller attributes based on programmed access levels. Installation is flexible with support for direct-wall mounting, 2x4 electrical boxes, or 1/4 DIN electrical boxes using standard #18 to #24 AWG wiring.

This sensor is ideal for commercial buildings, industrial facilities, and institutional applications requiring accurate zone temperature control and local user interface capabilities. UL and CSA certified for reliable performance and safety compliance.
