Beckett CB252UL Large Condensate Pump 230V 25 Ft Max Lift 1 Gallon

The Beckett CB252UL is a large capacity automatic condensate removal pump designed for high-volume applications including air conditioning equipment, dehumidifiers, high-efficiency furnaces, boilers, and condensing equipment. This 230V, 60Hz unit features a 1-gallon reservoir tank and delivers up to 122 GPH at 1 foot of lift with a maximum lift capacity of 25 feet.

Key Features:

• Built-in safety switch with separate overflow detection for added protection
• 1-gallon tank capacity with 3/8" discharge outlet
• 1/20 HP thermally protected fan-cooled motor drawing 0.90 amps (150 watts)
• 1.1" diameter inlet with 5/8" ID grommet for flexible connections
• Includes check valve, thermal protection, and stainless steel shaft as standard
• Hard-wired power connection with UL-rated terminal block
• UL/CUL listed for U.S. and Canada

This unit is capable of handling acidic condensation from condensing furnaces and tankless water heaters. The molded plastic design provides efficient and quiet operation with conduit connection capability. Features automatic on/off operation for hassle-free performance.

Performance Specifications: 122 GPH at 1 ft, 104 GPH at 5 ft, 82 GPH at 10 ft, 60 GPH at 15 ft, 37 GPH at 20 ft, 25 ft shutoff.
