Carrillo M9012 CP Pistons M Series Forged Piston and Ring Kit

The CP-Carrillo M9012 is a high-performance forged piston and ring kit engineered for powersports applications. Built from forged aluminum to withstand the extreme demands of performance and racing engines, this kit delivers the precision and durability that CP-Carrillo is known for worldwide.

Featuring a 95.00mm bore and 72.00mm stroke, the M9012 utilizes a floating wrist pin design for reduced friction and smoother operation under high-RPM conditions. The kit includes everything needed for a complete piston installation.

Key Features:

• Forged aluminum construction for superior strength-to-weight ratio
• 95.00mm bore / 72.00mm stroke precision specification
• Floating wrist pin design with wrist pin retainers included
• Steel top ring for excellent heat resistance and durability
• X-forging design minimizes friction and weight without compromising structural integrity
• Double pin oilers deliver twice the lubrication from the cylinder wall to the wrist pin
• Radiused dome maximizes quench area while eliminating hot spots that promote detonation
• Accumulator groove — a V-shaped groove machined into the second ring groove collects excess blowby between the top and second rings for improved ring seal
• Complete kit includes piston, pin, locks, and rings

CP-Carrillo pistons are manufactured using advanced CNC machining, CMM inspection, and FEA analysis to ensure every component meets exacting tolerances. This is a purpose-built powersports piston kit designed for riders and builders who demand race-proven performance.
