Carrillo M4006B High-Performance Forged Piston Kit for Suzuki Hayabusa 85mm Big Bore

The Carrillo M4006B is a high-performance forged piston kit engineered specifically for 1999-2007 Suzuki Hayabusa GSX1300R motorcycles. This precision-manufactured piston provides an 85mm bore size (+4mm oversize) with a 12.5:1 compression ratio, creating a displacement of 1429cc when paired with the stock 63mm stroke crankshaft.

Key Specifications:

• Bore Size: 85mm (+4mm oversize)
• Compression Ratio: 12.5:1
• Displacement: 1429cc (with 63mm stroke)
• Piston Part Number: M4006B
• Complete Piston Kit Number: CPK4006
• Compatible Rod Number: 4720
• Wrist Pin: 787-2000-12CP1C
• Locks: 787x050 SWL
• Ring Set: CPNG-2-3346
• Gasket: C8659

CP-Carrillo pistons are forged from proprietary aluminum alloy and manufactured to exacting tolerances for maximum strength, durability, and reliability in high-performance and racing applications. This big bore piston kit is designed to increase engine displacement and power output while maintaining excellent piston-to-wall clearances and ring seal. Ideal for naturally aspirated performance builds seeking additional horsepower and torque.
