Diversi-Tech WG840595 Wagner Direct Drive Furnace Blower Motor 1HP 115V 1075/3-Speed

The Diversi-Tech Wagner WG840595 is a 1 HP, 115V, 3-speed direct drive furnace blower motor built for reliable, long-term performance in residential and commercial HVAC applications. Operating at 1075 RPM with a full load amperage of 12.6 FLA, this motor fits all standard NEMA 48 frame mounting brackets and supports belly band, shaft-up, and shaft-down mounting configurations.

Key Features:

• 1 HP / 115V / 60 Hz — single-phase, 3-speed operation at 1075 RPM
• Ball bearing design — delivers superior heat endurance, improved performance, and extended motor life
• Electrically reversible — rotation direction changed easily via included reversing plug; no rewiring required
• Automatic thermal overload protection — built-in protection against overheating
• Class B insulation — rated for up to 140°F operating temperature
• Standard NEMA 48 frame — installs with all standard 48 frame mounting brackets
• Open air-over (OAO) enclosure — continuous duty rated
• 1/2 in. diameter x 4-1/2 in. shaft with one flat for secure blower wheel attachment
• Uses 370V run capacitor — required capacitor size is printed on the motor carton for quick reference
• Extended thru-bolts — simplify installation in tight spaces; allows fast threading of mounting nuts
• 36-inch lead wires — extra wire length eases installation and connections
• 2.5 in. diameter hub rings included
• Low power consumption — energy-efficient design

The WG840595 is part of DiversiTech's Wagner motor line and ships in protective foam cradle packaging that safeguards the motor, shaft, and mounting hardware during transit. A detailed wiring diagram is printed directly on the motor and on the carton for fast, accurate installation.
