FuelTech 3020004086 Staging Brake Control Solid State Relay 20A 12V

Manufacturer

Picture for manufacturer FuelTech

Part Number

3020004086
6 reviews
Sale Price

$131.87

3 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The FuelTech Staging/Brake Control Solid State Relay is a high-performance 12V relay designed specifically for use with FuelTech engine management systems. This compact solid-state relay provides reliable switching for staging control and brake control functions in racing applications.

Key Features:

  • Compatible with FT600, FT550, FT500, FT500LITE, and FT450 ECUs for built-in staging and brake control
  • Fast switching speed ideal for PWM control applications with frequency range of 0-1000Hz
  • Solid-state design with no mechanical parts for enhanced reliability and silent operation
  • Maximum current capacity of 20 amps with normally open contact configuration
  • Compact dimensions: 1.07" x 1.07" x 1.02" (27mm x 27mm x 26mm)

Electrical Connections:

  • Pin 30: Switched 12V (use fuse)
  • Pin 85: Not connected
  • Pin 86: Trigger input from FT auxiliary output (activated when switched to ground)
  • Pin 87: Output for load - Normally Open contact - 20A maximum

This solid-state relay eliminates the clicking noise and potential failure points of mechanical relays while providing precise control for drag racing staging systems and brake control applications. Perfect for high-performance racing applications requiring fast, reliable switching.

Great pricing

Great

Order was sent in the timeframe stated. Exact part as described.

Best price. Quick delivery. All done from the comfort of home. Doesn't get any better than that!

Shipping wasn't on time That's Only problem.

Shopping experience was good, but the picture does not match the item. Leads to confusion.
