Carrillo SC7476LR-3 Forged Piston and Ring Set Toyota Yaris G16E-GTS 87.51mm +4mm 10.5:1 CR 3-Cylinder

The Carrillo SC7476LR-3 is a high-performance forged piston and ring set engineered specifically for the Toyota Yaris G16E-GTS 3-cylinder turbocharged engine. This complete kit features a 87.51mm bore size (+4mm oversize) with a 10.5:1 compression ratio, designed for use with Carrillo 4mm long connecting rods and 22mm wrist pins.

Key Features:

• Forged from high-strength 2618-T61 aluminum alloy for superior durability under high heat and cylinder pressure
• 87.51mm (3.4453") bore diameter, +4mm oversize from standard
• 10.5:1 compression ratio optimized for performance applications
• 147.75mm compression height (29.8mm deck height)
• Designed for use with Carrillo 4mm long connecting rods (LR designation)
• 22mm wrist pin diameter with chromoly pins and wire locks included
• Complete ring package with precision-matched compression and oil rings
• Advanced cam and barrel skirt profile for optimal piston-to-wall clearance

CP-Carrillo pistons are manufactured with computer-designed forgings, CNC machined to tight tolerances, and undergo rigorous quality control inspection. The 2618-T61 alloy provides excellent strength characteristics for turbocharged, supercharged, and high-performance naturally aspirated applications. Each piston set includes everything needed for installation: forged pistons, performance ring sets, chromoly wrist pins, and retaining locks.

Note: This product is not CARB legal and is not for sale in California. Professional installation and proper engine machining recommended to verify piston-to-wall clearance, ring end gaps, and deck height.
