FAG VAS1 Pillow Block Ball Bearing Unit

The FAG VAS1 is a standard duty pillow block ball bearing housed unit from the VAS Standard Series, featuring a 1 inch bore diameter designed for reliable shaft support in industrial applications. This ball bearing housed unit combines the bearing, housing, seal and locking system into one device for easy installation and operation.

Key Features:

• Two-bolt base mounting with cast iron construction
• Eccentric locking device for secure shaft retention
• Contact seal design for contamination protection
• Pre-lubricated with grease fitting provided for relubrication
• Non-expansion (fixed) type bearing
• Can be mounted to operate in any position

Specifications:

• Bore Size: 1 inch
• Bolt Center-to-Center: 4-1/8 inches
• Base to Bore Centerline: 1-7/16 inches
• Overall Dimensions: 5-1/2" L x 1-7/32" W x 2-13/16" H
• Base Width: 1-13/32 inches
• Dynamic Load Rating: 3,490 lbs
• Static Load Rating: 1,760 lbs
• Maximum Temperature: 250°F
• Maximum Speed: 5,440 RPM

The VAS series pillow blocks are designed to be interchangeable with certain competitive designs while maintaining superior load carrying capacity. Ideal for conveyor systems, processing equipment, and general industrial machinery requiring dependable bearing support.
