TiAL 007321 V50D 50mm Compressed Gas External Wastegate 0.32 Bar 4.64 PSI Black

The TiAL 007321 V50D is a high-performance 50mm compressed-gas external wastegate engineered specifically for high-pressure 'top-down' boost control systems. Featuring a 0.32 bar (4.64 psi) spring pressure, this wastegate is designed from the ground-up for demanding turbocharging applications including drag racing and road racing.

Advanced Compressed Gas Technology:

• Unique inverted diaphragm design provides sealing for up to 120 psi of control gas pressure
• Reduced-size actuator housing minimizes fill rates and enhances response time
• Low-pressure spring configuration provides quick boost relief during staging and launching
• Dual-port diaphragm chamber with M10 signal ports ensures accurate boost control under all conditions

Premium Construction:

• CNC-machined aluminum actuator housing for lightweight durability
• High-temperature alloy valve with proprietary TiAL wear coating on valve stem
• Stainless steel valve housing for extended service life
• Nomex-reinforced silicone diaphragm for high-temperature reliability
• All stainless steel and aluminum construction throughout

Features:

• 50mm valve size optimized for applications sensitive to exhaust manifold pressure-induced valve lift
• Same form factor as the legendary TiAL V50 and V60 series
• Compatible with retrofit kits for easy conversion of existing models
• Black anodized finish (only color available for V50D models)
• Fully engineered in-house by TiAL's motorsport engineering team
• Made in USA

The V50D represents the ultimate solution for turbocharged applications requiring precise compressed-gas boost control with maximum reliability under extreme racing conditions.
