TiAL 005015 External Wastegate Bar - V50 50mm 52 Blue

The TiAL V50 External Wastegate is a high-performance 50mm wastegate engineered for precision boost control in demanding turbocharged applications. This unit features a .52 Bar (7.54 PSI) spring pressure and comes with a blue anodized billet aluminum actuator housing for both aesthetic appeal and lightweight durability.

Construction and Materials:

• High-temperature alloy valve and lower housing for extended service life
• CNC machined billet aluminum actuator housing in blue anodized finish
• Nitronic 60 valve guides and seats for superior corrosion and galling resistance
• 17-7 PH stainless steel actuator spring maintains consistent pressure at elevated temperatures
• High-temperature silicone reinforced actuator diaphragm
• 304L stainless steel mating weld flanges
• All stainless steel hardware included

Performance Features:

• 50mm valve size optimized for applications sensitive to exhaust manifold pressure-induced valve lift
• Optimized actuator-to-valve area ratio for maximum control and wide dynamic flow capacity
• Dead-on accurate boost control in the most demanding racing situations
• M10 air signal ports for easy installation

What's Included:

• V50 wastegate assembly with .52 Bar spring
• Stainless steel band V-clamps and flanges
• CNC machined air fittings (stainless steel and aluminum)

A proven favorite in drag racing and road racing industries, the TiAL V50 wastegate delivers professional-grade boost control with exceptional durability. The V50 shares the same compact form factor as the legendary V60 but offers a smaller valve size for enhanced versatility across a broader range of turbo setups.
