Hydrolevel VXTC-WF Programmable Automatic Water Feeder for Commercial Boilers 120V

The Hydrolevel VXTC-WF is a programmable automatic water feeder designed for commercial steam boilers, featuring a Y-strainer and flow restrictor. This model is supplied without a water meter, making it ideal for installations where metering is not required or is handled separately.

Key Features:

• Compatible with all major low water cut-offs and pump controllers, both float-type and probe-type
• Programmable delay feature (0 to 10 minutes) allows condensate to return to the system before initiating a feed cycle
• Five programmable feed settings to meet the needs of virtually any boiler application
• Manual feed capability with the touch of a button for maintenance and testing
• Lock-out safety feature after a sustained 10-minute feed cycle prevents flooding from malfunctioning controls
• Multi-purpose LED display indicates current operating mode: delay, feed, standby, or lock-out
• High flow rate of 10 GPM at 40 PSI for rapid boiler filling

Technical Specifications:

• Voltage: 120 VAC, 60 Hz
• Maximum feed water temperature: 100°F
• Connection: 3/4" NPT fittings
• Maximum pressure: 150 PSI

What's Included:

• VXTC controller module
• 3/4" NPT Y-strainer
• 10 GPM flow restrictor
• 3/4" NPT solenoid valve
• Brass adaptors with connection gaskets

Hydrolevel combines years of water feeder experience with advanced microchip technology and increased flow rates essential for commercial applications. The VXTC-WF provides reliable, programmable water feed control to maintain proper boiler water levels and protect against low-water conditions.

Note: This model has been discontinued and replaced by part number 45-127, which offers identical functionality with no modifications to the product.
