FAG B2414 Drawn Cup Needle Roller Bearing

The FAG B2414 is a full complement drawn cup needle roller bearing designed for applications requiring high radial load capacity in confined spaces. This bearing features a thin-walled drawn steel outer cup that provides excellent load-carrying capabilities while minimizing the required mounting space.

Key Specifications:

• Bore Diameter: 1.5 inches (38.1mm)
• Outer Diameter: 1.875 inches (47.625mm)
• Width: 0.875 inches (22.23mm)
• Basic Dynamic Load Rating: 43.5 kN (9,780 lbs)
• Basic Static Load Rating: 87.5 kN (19,670 lbs)
• Maximum Speed: 4,300 RPM

Features and Benefits:

• Full complement of needle rollers provides maximum radial load capacity without a cage
• Through-hardened, high-carbon chromium steel rollers for superior durability and heat tolerance
• Compact, thin-walled design ideal for applications with limited mounting space
• Drawn steel outer shell serves as the raceway, reducing overall bearing cross-section
• Open design allows for easy installation with press fit mounting
• Operating temperature range: -30°C to +110°C (-22°F to +230°F)

This bearing is commonly used in automotive and truck transmissions, agricultural and construction equipment, pumps, compressors, and two-cycle engines. For optimal performance, use with a hardened and ground shaft or inner ring. Also known as S-2414 or B2414 in cross-reference applications.
