RectorSeal 96128 AquaGuard AG-3180E Condensate Overflow Sensor with Time Delay

The RectorSeal AquaGuard AG-3180E micro-electronic condensate sensor is mounted directly in the primary drain pan, making it the ideal solution for commercial package units and rooftop HVAC systems. This sensor is designed to prevent water damage to floors, walls and ceilings from condensate overflow by shutting off the cooling system when water levels in the drain pan reach a certain level.

Key Features:

• Time delay up to 60 seconds
• Bonus secondary sensor features a water detection LED and easily installs in metal or plastic secondary drain pans
• 6 feet of both plenum rated probe and sensor wire
• 5 amp, 24 VAC solid state sensor with patent pending Smart Sensor technology
• Switch can be normally open or normally closed
• Normally open 4th wire for optional external alarm, digital controller or energy management systems
• Adjustable mounting clips and can also be mounted with double sided tape
• cUL/UL Listed (UL 508 approved)

Both sensors continuously monitor any condensate overflow in the primary and secondary drain pans and automatically shut off the system and activate an alarm if any overflow is detected in as little as 1/16" of water in either drain pan. Meets International Building Codes and Primary Pan Code Requirements.
