Fireye 60-2852-1 BurnerLogix Closed Wiring Base with Terminal Block and Knockouts

The Fireye 60-2852-1 is a closed wiring base designed for use with BurnerLogix Z flame safeguard control systems, offering a sealed wiring compartment suitable for mounting outside of a cabinet. This UL Recognized mounting base measures 4 inches wide by 7 inches high, providing a compact and secure platform for BurnerLogix chassis modules including ZB110 and ZB230 models.

Key Features:

• Closed wiring compartment design suitable for external cabinet mounting
• Knockouts located along the bottom surface for flexible conduit entry
• Integral terminal block located outside the control mounting area for organized wiring
• Terminal block accepts up to 2 x 14 AWG wires
• Terminal block screw torque rating: 4.4 to 5.3 in-lbs
• Dual mounting options: DIN rail or direct panel mount using #10-32 screws
• Knockouts can be removed with a screwdriver or blunt force greater than 10 lbs

The terminal block design allows easy troubleshooting access to all BurnerLogix control terminals without removing the control from the base. Access to the wiring compartment is gained by loosening (not removing) the screws securing the housing compartment cover. This wiring base is compatible with BurnerLogix microprocessor-based burner management control systems used for flame safeguard protection on oil, gas, and combination fuel burners.
