Aaon OE258-01 Building Static Pressure Sensor

The Aaon OE258-01 is a building static pressure sensor designed for commercial HVAC applications requiring precise pressure monitoring and control. This sensor measures building static pressure to help maintain optimal indoor air quality and system efficiency in rooftop units and other HVAC systems.

Key Specifications:

• Pressure range: -0.25 to +0.25 inches water column (W.C.)
• Output signal: 0-5 VDC analog output
• Power requirements: 24 VAC/VDC
• Connection: 3-conductor field wiring
• Compatible with Aaon VCCX2 controllers and similar building automation systems

Features:

• Accurate measurement of building static pressure for demand control ventilation
• Low differential pressure range ideal for building pressurization control
• Voltage output proportional to measured pressure for integration with control systems
• Designed specifically for Aaon rooftop units and commercial HVAC equipment

This sensor connects to HVAC controllers to provide real-time pressure data for system diagnostics and troubleshooting, enhancing operational reliability and energy efficiency. Also identified by alternate part numbers ASM01832 and R37030. Note that tubing is not included and must be ordered separately.
