Belimo B215HT073 2-Way High Temperature Characterized Control Valve 1/2" NPT 0.73 Cv

Manufacturer

Part Number

B215HT073
Sale Price

$118.90

1 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Belimo B215HT073 is a 2-way High Temperature Characterized Control Valve (HTCCV) designed for precise, reliable flow control in demanding HVAC hydronic systems. With a 1/2" female NPT connection and a Cv rating of 0.73, this valve body is engineered for two-position, floating, or proportional control of hot water, chilled water, or low-pressure steam.

The HTCCV series combines the high close-off capability of a ball valve with a characterized disc that delivers a true equal percentage flow characteristic, providing superior light load flow control throughout the full range of operation. The valve body is compatible with a range of Belimo TR, LR, and TFR series electric actuators with spring return or non-spring return operation (actuator sold separately).

Key Features:

  • Configuration: 2-way, normally closed characterized control valve (HTCCV)
  • Connection: 1/2" female NPT
  • Cv Rating: 0.73 (1.46 GPM @ Δ4 psi)
  • Close-Off Pressure: 200 psi
  • Leakage: 0% — bubble-tight shutoff
  • Media Temperature Range: 60°F to 266°F (16°C to 130°C) for water; up to 250°F (121°C) for steam
  • Media Compatibility: Hot or chilled water, glycol solutions up to 60%, low-pressure steam up to 15 psig
  • Body Material: Dezincification-resistant brass (DZR) — P-CuZn35Pb2
  • Ball and Stem: Stainless steel
  • Disc and Seat: Tefzel® characterized insert
  • Seals: EPDM O-rings
  • Flow Characteristic: True equal percentage
  • Maintenance: Maintenance-free design
  • Weight: 0.7 lb

Typical Applications:

  • Air handling unit (AHU) heating and cooling coils
  • Fan coil unit (FCU) heating and cooling coils
  • Unit ventilators
  • VAV box re-heat coils
  • Hydronic bypass loops
  • Variable flow hydronic systems

The B215HT073 valve body is designed to fit in compact spaces and is suitable for use with 24 VAC actuators providing on/off, floating point, or modulating control. It is compatible with Belimo TR (non-spring return) and TFR (spring return) actuator series.
