Sporlan Controls 904062 HGBE-8 7/8" ODF Discharge Bypass Valve Externally Equalized 75/150 PSIG

The Sporlan Controls 904062 HGBE-8 is a 7/8" ODF discharge bypass valve with externally equalized design and an adjustable pressure range of 75-150 PSIG. This discharge bypass regulating valve (DBV) is designed to limit the minimum evaporating pressure during periods of low load, either to prevent coil icing or avoid operating the compressor at a lower suction pressure than it was designed to operate.

Key Specifications:

• Inlet Size: 7/8" ODF
• Outlet Size: 7/8" ODF
• Pressure Range: 75/150 PSIG (Adjustable)
• Equalizer Method: Externally Equalized with 1/4" SAE connections
• Connection Type: Solder (ODF)
• Connection Material: Copper
• Body Material: Brass
• Design Working Pressure: 700 PSI for HGB-8 valves

Features and Benefits:

• Adjustable pressure settings for precise system control
• Factory tested to ensure positive leak-free performance
• Direct acting valve design with ODF connections
• Suitable for air conditioning, refrigeration, industrial refrigeration, and transportation applications

Manufactured by the Sporlan Division of Parker Hannifin, a company with over 80 years of experience setting industry standards for HVACR components. This valve is ideal for use in residential and commercial air conditioning units, packaged units, chillers, coolers, freezers, and walk-in refrigeration systems.
