Johnson Controls VG1245DPH958BGA 1-1/4 Inch NPT Ball Valve with VA9208-BGA-3 Electric Actuator

The Johnson Controls VG1245DPH958BGA is a complete valve assembly combining a Model VG1245DP two-way stainless steel trim NPT ball valve with a Model VA9208-BGA-3 thermal barrier electric actuator. This industrial-grade valve assembly is designed for demanding HVAC applications requiring precise two-position control of hot or chilled water systems.

Valve Specifications:

• 1-1/4 inch NPT threaded connections for easy installation
• Flow coefficient (Cv) of 18.7 for optimal flow characteristics
• Two-way ball valve design with stainless steel trim for corrosion resistance
• Suitable for water, glycol solutions, and other compatible fluids

Actuator Features:

• 24-volt AC/DC electric actuator for reliable operation
• Two-position control (open/closed) with non-spring-return operation
• Thermal barrier construction protects actuator electronics from extreme fluid temperatures
• Closed position without power (non-spring-return requires power to change position)
• Without auxiliary switch for simplified wiring in basic applications

This valve assembly is ideal for commercial HVAC systems, hydronic heating and cooling applications, and process control systems where reliable two-position control is required. The thermal barrier actuator extends service life in high-temperature applications by isolating the actuator electronics from heat transfer through the valve body.
