Johnson Controls VG1245DPH938BGC 1-1/4" NPT Ball Valve with VA9208-BGC-3 Spring Return Actuator

The Johnson Controls VG1245DPH938BGC is a complete valve and actuator assembly featuring a VG1245DP two-way stainless steel trim NPT ball valve paired with a VA9208-BGC-3 electric actuator. This assembly is designed for precise fluid control in commercial HVAC systems, providing reliable on/off control for hot water, chilled water, and glycol applications.

Valve Specifications:

• Port size: 1-1/4 inch NPT threaded connections
• Flow coefficient (Cv): 18.7
• Two-way ball valve design with stainless steel trim for corrosion resistance
• Suitable for water, steam, and glycol solutions
• Pressure rated construction for HVAC applications

Actuator Specifications:

• Model VA9208-BGC-3 electric actuator with thermal barrier protection
• 24V AC/DC power supply
• Open spring-return operation (fails open on power loss)
• Two-position control (fully open or fully closed)
• Two auxiliary switches for status indication and control integration
• Thermal barrier design protects actuator from heat transfer in hot water systems
• Direct-coupled mounting for compact installation

This valve assembly arrives fully assembled and tested, ready for installation in hydronic heating and cooling systems, boiler applications, and commercial HVAC equipment. The spring-return actuator ensures fail-safe operation by automatically opening the valve during power failure, making it ideal for safety-critical applications.
