Browning VF4S-216 Normal-Duty 4-Bolt Flange Ball Bearing Unit 1" Bore Set Screw Lock Cast Iron

The Browning VF4S-216 is a normal-duty, four-bolt flange mounted ball bearing unit designed for reliable performance in general industrial power transmission applications. Featuring a 1-inch bore with set screw locking, this unit mounts securely to flat surfaces using a four-bolt pattern, providing excellent stability and load distribution across the mounting flange.

The housing is constructed from durable cast iron and houses a 52100 bearing steel insert with a black oxide coated inner ring for added corrosion resistance. A single lip contact seal combined with a flinger seal protects the bearing from contamination while retaining lubrication, making it well-suited for dusty or moderately harsh environments. The unit is pre-lubricated with Lithium Complex NLGI 2 grease and is regreasable for extended service life.

Key Features:

• Normal-duty, four-bolt flange mounted ball bearing unit
• 1" bore with set screw shaft locking
• Cast iron housing — durable and rigid
• 52100 bearing steel insert with black oxide coated inner ring
• Single lip contact seal with flinger seal for dual contamination protection
• Regreasable design for extended maintenance intervals
• Pre-lubricated with Lithium Complex NLGI 2 grease
• 2-3/4" bolt hole spacing width; 3-3/4" overall width
• Non-expansion (fixed) bearing configuration
• Replacement bearing insert: VS-216
• Vendor Part Number: 767623 | UPC: 662289522613

The VF4S-216 is a proven solution for fans, blowers, conveyors, and a wide range of industrial machinery requiring dependable flanged bearing support.
