Reznor 211412 OMRON LY2 Relay Socket 110/120 VAC DPDT

The Reznor 211412 is a genuine OEM replacement relay socket assembly designed for Reznor unit heaters and heating systems. This component houses an OMRON LY2-AC110/120 general purpose relay, a critical control component used in industrial and commercial heating equipment.

Key Specifications:

• Coil Voltage: 110/120 VAC (operates within 88-132 VAC range)
• Contact Configuration: DPDT (Double Pole Double Throw / 2 Form C)
• Contact Rating: 10 Amp at 120 VAC, 15 Amp maximum
• Contact Material: Silver cadmium oxide for long life and reliability
• 8-Pin Plug-in Socket: Easy installation and replacement
• Contact Resistance: 100 milliohms maximum
• Operating Time: 30 milliseconds maximum
• Release Time: 25 milliseconds maximum

Features and Benefits:

• UL-recognized component and CSA certified for safety compliance
• Plug-in design allows for quick field replacement without soldering
• DIN rail or surface mounting options provide installation flexibility
• Bi-power relay design ensures reliable switching in control panel applications
• Genuine Reznor OEM part ensures proper fit and function
• Compatible with multiple Reznor heater models including UDAP, UEAS, F, and FE series

This relay socket assembly plays a critical role in the safe operation and proper cycling of Reznor heating systems, controlling electrical circuits for blower motors, ignition systems, and safety controls. When replacing electrical components, always ensure power is disconnected and follow proper safety procedures.
