Honeywell VBN2CPPA1001 1-Inch NPT 2-Way Brass Ball Valve with 24V Floating Actuator

The Honeywell VBN2CPPA1001 is a 2-way threaded control ball valve designed to control hot and chilled water with glycol solutions up to 50% in heating, ventilating, and air conditioning (HVAC) systems. This 1-inch NPT valve features a flow coefficient (Cv) of 54, making it suitable for medium to high flow applications.

Key Features:

• Floating control with two-position SPDT operation and 90-second timing, 24V, fail-in-place design
• 1-inch female NPT threaded connections for easy installation
• Equal percentage flow characteristic with flow control insert for precise modulation
• Forged brass body (ASTM B283) with nickel-chrome plated brass ball and stem
• Compatible with water and glycol solutions, not for use with steam or fuels
• ANSI Class IV leakage rating (0.01% of CV maximum) for tight shutoff
• Maximum static pressure of 360 psi at 250°F
• 27 lb-in. (3 Nm) actuator torque with 90° rotational stroke
• Rangeability of 1207:1 for excellent controllability
• Removable manual operating handle for installation or power failure operation

The VBN valves use a patented seat design that reduces the torque needed from the actuator, ensuring reliable operation and long service life. This valve assembly comes with a factory-installed MVN-series non-spring return actuator, providing integrated control right out of the box for HVAC applications.
