Asco 8215C53-24V 1 Inch 2-Way Normally Open Solenoid Valve

The Asco 8215C53-24V is a 1-inch normally open solenoid valve designed for low-pressure applications operating at 0-25 PSI with a 24V DC power supply. This 2-way internal pilot-operated solenoid valve features a rugged aluminum body with trim and internal parts made of steel and stainless steel. Engineered as a direct acting or piloted solenoid valve for air and vacuum service, it's ideal for low pressure applications.

Key Features:

• Normally open valve type - valve remains open when de-energized
• 1-inch NPT female inlet and outlet connections
• 24V AC voltage with 15.4 watt rating
• 22 Cv flow coefficient for efficient flow capacity
• 1-5/8 inch orifice size
• Suitable for pressures from 0-25 PSI for both air and gas applications
• Manual override feature for emergency operation
• NEMA 1 housing type with watertight construction

Technical Specifications:

• Aluminum body construction with steel and stainless steel internals
• NBR (Nitrile Butadiene Rubber) seat material
• Operating temperature range: 32°F to 125°F ambient, up to 125°F fluid
• Gas capacity: 1,191,750 BTU/hr
• 18-inch lead wire length
• Vertical and upright mounting orientation
• Copper shading ring for reliable AC operation

This ASCO Red-Hat series valve is UL listed for general purpose use. The 8215C53-24V is suitable for HVAC systems, industrial equipment, and other low-pressure applications requiring reliable venting. Commonly used in pneumatic conveying systems, air compressors, gas lines, and a variety of industrial and commercial applications.
