Johnson Controls VG7241NT+3008B 1" NPT Normally Open 2-Way Pneumatic Globe Valve with V-3000 Actuator

Manufacturer

Part Number

VG7241NT+3008B
Black Friday Price

$424.68

In Stock (10+)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Johnson Controls VG7241NT+3008B is a complete valve assembly combining a 1-inch NPT two-way globe valve with brass trim and an integrated V-3000 Series pneumatic actuator. This normally open (N.O.) configuration features spring return fail-safe operation, making it ideal for hot water, chilled water, and steam control applications in commercial HVAC systems.

Key Features:

  • 1-inch female NPT threaded connections for easy installation
  • Flow coefficient (Cv) of 11.6 for precise flow control
  • 3-6 PSI spring range with 8 square inch effective diaphragm area
  • Brass trim construction with ANSI Class IV leakage rating (0.01% of maximum flow)
  • Equal percentage flow characteristic with 25:1 rangeability
  • Spring return normally open fail-safe position
  • Compact exposed yoke design with die-cast aluminum actuator housing
  • Molded synthetic rubber diaphragm for consistent performance
  • 1/2-inch (13 mm) valve stem stroke
  • Maximum recommended pressure drop: 35 psid for water, 15 psid for steam with brass trim

The V-3000 pneumatic actuator positions the valve modulating plug in direct response to pneumatic control signals from a building automation controller. The exposed yoke design is suitable for installation in protected indoor locations. The actuator operates on air pressure up to 30 psig and features a 1/8-inch NPT barb fitting for 5/32-inch O.D. polytubing connection. This assembly replaces legacy model V-3754-1023 and is compatible with optional V-9502 pilot positioners for enhanced control stability or sequential operation.
