Johnson Controls VG7243LT+7150G Series VG7000 3/4" Stainless Steel Trim Globe Valve with VA-7150-1001 Non-Spring Return Electric Actuator

Manufacturer

Part Number

VG7243LT+7150G
Black Friday Price

$791.42

2 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Johnson Controls VG7243LT+7150G is a factory-assembled combination of the Series VG7000 bronze globe valve body with stainless steel trim and the VA-7150-1001 non-spring return floating electric actuator. This pre-matched valve and actuator assembly is engineered for precise flow control of hot water, chilled water, glycol solutions, and steam in commercial and industrial HVAC systems.

The VG7243LT globe valve body features a 3/4-inch NPT end connection with a two-way, normally open (push-down-to-close) configuration and a Cv of 6.3, delivering accurate and repeatable flow regulation. The cast bronze body is fitted with a stainless steel stem, stainless steel plug and seat, and spring-loaded PTFE/elastomer V-ring packing for long service life and tight shutoff across a wide range of media temperatures.

The VA-7150-1001 actuator provides non-spring return, floating (tri-state) control operation at 24 VAC/VDC, making it compatible with standard building automation and direct digital control (DDC) systems. The non-spring return design retains valve position on power loss rather than driving to a fail-safe position, suitable for applications where position retention is preferred.

Key Features:

  • Valve Size: 3/4 inch NPT (Female)
  • Flow Characteristic: Two-way, Normally Open (Push-Down-to-Close)
  • Flow Coefficient (Cv): 6.3
  • Valve Body: Cast bronze with stainless steel trim (stem, plug, and seat)
  • Packing: Spring-loaded PTFE/elastomer V-ring for low leakage and long life
  • Media Compatibility: Hot or chilled water, glycol solutions up to 50%, and low-pressure steam
  • Actuator Model: VA-7150-1001 Non-Spring Return Electric Actuator
  • Control Type: Floating (tri-state) — Open, Close, Stop signals
  • Actuator Voltage: 24 VAC/VDC
  • Actuator Operation: Non-spring return (position retained on power loss)
  • Factory-Assembled: Valve and actuator matched and assembled at the factory for reliable performance

The VG7243LT+7150G is ideal for zone control, terminal unit coil control, and heat exchanger applications in HVAC systems requiring reliable modulating or two-position flow control with a compact, proven valve-actuator package.
