Honeywell Q605D1069 Damper Linkage Kit for Modutrol Motors

The Honeywell Q605D1069 Damper Linkage Kit is a comprehensive linkage assembly designed to connect Modutrol motors to standard dampers or sets of dampers for precise control of duct airflow in HVAC systems. This versatile kit supports both internal and external duct mounting configurations, making it suitable for a wide range of commercial and industrial building automation applications.

Complete Kit Includes:

• Motor mounting bracket for secure installation
• Three damper arms for flexible configuration
• Motor crank arm for motor connection
• Four ball joints for articulating connections
• Left hand drive ear for directional mounting
• Crank arm adapter for compatibility

Key Features:

• Adjustable to any degree of damper opening for precise airflow control
• Designed for 1/2 inch (13mm) diameter shaft applications
• Compatible with Honeywell Modutrol Series 71, 72, and 76 motors
• Suitable for both internal and external motor mounting
• Made in the United States

This Super Tradeline damper linkage kit provides HVAC professionals with all the necessary components to establish a reliable mechanical connection between actuators and dampers. The adjustable design allows for custom positioning to achieve optimal airflow control in commercial building management systems.
