Konig HL88514428 Heliogram Flow Formed Wheel Matte Bronze Offset - 18x8.5 5x114.3 42mm

The Konig Heliogram is a motorsport-inspired split 5-spoke wheel engineered with advanced flow-forming technology to deliver exceptional strength and reduced weight. This innovative manufacturing process applies pressure to the inner barrel while spinning after casting, stretching and compressing the aluminum to increase tensile strength with properties similar to forged wheels.

Key Features:

• Flow-formed construction for lighter weight and superior strength compared to traditional cast wheels
• Split 5-spoke design in matte bronze finish
• Knurled bead seat to prevent tire slippage in high-torque motorsports applications
• One-piece lightweight aluminum construction
• Size: 18x8.5 inches
• Bolt pattern: 5x114.3mm (also fits 5x112mm and 5x108mm)
• Offset: +42mm (ET42)
• Hub bore: 73.1mm
• Load rating: 1,543 lbs
• Weight: 18.57 lbs per wheel
• Backspacing: 6.4 inches

Engineered using Finite Element Analysis (FEA) and advanced simulation software, the Heliogram offers increased shock resistance, enhanced tensile strength, and superior elongation properties. The knurled bead seat design ensures tire security during aggressive driving and high-torque applications, making it ideal for both street and track use.
