The ACT BM13-HDG4 is a Heavy Duty Race Sprung 4-Pad clutch kit engineered for high-horsepower street and race applications. This kit pairs ACT's most popular Heavy Duty pressure plate with a 4-pad spring-centered race disc, delivering aggressive engagement characteristics, faster shifts, and the durability to handle demanding performance use.
Heavy Duty Pressure Plate
ACT's exclusive diaphragm design increases clamp load while reducing deflection to maximize clutch life. Each diaphragm undergoes a four-stage heat-treating process for consistent, high-performance clamping force. Precision cover stampings add rigidity and dimensional consistency, and every unit is 100% clamp load tested before it leaves the factory.
4-Pad Spring-Centered Race Disc
The spring-centered hub design properly dampens torsional vibrations for quieter operation compared to a rigid disc, while still resisting failure under harsh race conditions. Select ceramic friction materials provide high heat tolerance and maximum performance. ACT's spring retainers feature wraparound spring windows and thicker retainer stampings that reduce stress concentrations and increase overall strength and reliability. This 4-pad configuration is particularly well-suited for smaller disc sizes found in smaller-displacement engines.
Key Features:
- Light-to-moderate pedal effort with aggressive, performance-oriented engagement
- Select ceramic friction materials for high heat tolerance
- Spring-centered disc dampens torsional vibrations and reduces gear rattle
- Exclusive diaphragm design increases clamp load and extends friction life
- Four-stage heat-treated diaphragms for unparalleled durability
- Precision cover stampings for rigidity and consistency
- Wraparound spring windows and thicker retainer stampings for added strength
- 100% clamp load tested at the factory
- Dynamically computer balanced to within 0.25 oz-in for smooth high-RPM operation
- Recommended for high-horsepower street or race use
ACT race discs typically require only a few firm slips to lap in friction surfaces before normal driving or racing. Expect a 15–40% increase in pedal effort compared to a stock clutch — a deliberate trade-off that ensures proper torque capacity, engagement quality, and long-term longevity.
