The ACT BM12-HDG4 is a Heavy Duty Race Sprung 4-Pad clutch kit designed for high-horsepower street performance and competitive racing applications. This conversion kit includes ACT's Streetlite flywheel, pressure plate bolts (M8-1.25 x 20mm), and flywheel bolts (M12-1.5 x 30mm), making it a complete drivetrain upgrade in a single package.
Heavy Duty Pressure Plate:
The BM12-HDG4 features ACT's most popular Heavy Duty pressure plate, engineered with an exclusive diaphragm design that increases clamp load, reduces deflection, and maximizes clutch life. All diaphragms undergo a rigorous four-stage heat-treating process for consistent, high-performance operation. Precision cover stampings ensure rigidity and dimensional accuracy across the entire assembly.
4-Pad Spring-Centered Race Disc:
The spring-centered race disc uses select ceramic friction materials for outstanding heat tolerance and maximum torque transfer. The spring center properly dampens torsional vibrations for quieter operation and improved durability under harsh conditions. ACT's spring retainers feature wraparound spring windows and thicker retainer stampings to reduce stress concentrations and improve long-term reliability. The 4-pad configuration delivers faster, more direct shifting in exchange for a more aggressive engagement feel — making it particularly well-suited for smaller disc sizes in smaller displacement engines.
Key Features:
- Light to moderate pedal effort with aggressive engagement character
- Select ceramic friction materials for high heat tolerance and maximum performance
- Exclusive diaphragm design extends friction life and maximizes clamp load
- Four-stage heat-treated diaphragms for unparalleled durability
- 100% clamp load tested at the factory for quality assurance
- Dynamically computer balanced to within 0.25 oz-in for smooth high-RPM operation
- Recommended for high-horsepower street or race use
- Conversion kit — includes ACT Streetlite flywheel, flywheel bolts, and pressure plate bolts
- Input shaft: 1-1/8" diameter, 10-spline (5-speed transmissions)
ACT (Advanced Clutch Technology) clutches are carefully engineered, precisely assembled, and accurately balanced to deliver reliable performance in demanding conditions. The BM12-HDG4 is flagged by ACT as not recommended for standard street use — it is purpose-built for performance and race applications.
