Hella 965400101 12V 4-Pin Mini ISO Relay with Mounting Bracket

The Hella 965400101 is a 12-volt, 4-pin Mini ISO relay with an integrated mounting bracket, engineered for multi-purpose electrical load management in automotive systems. Built to the same standards as Hella's original equipment components, this relay delivers dependable switching performance across a wide range of vehicle applications.

Key Features:

• Operating Voltage: 12V DC
• Configuration: 4-pin, normally open (SPST) make contact
• Maximum Switching Current: 30A
• Coil Resistance: 320 Ohm for stable, consistent coil performance
• Load Compatibility: Suitable for ohmic (resistive), inductive, and capacitive loads
• Service Life: Rated for up to 100,000 switching operations
• Mounting: Integrated bracket for fast, secure installation in vehicle electrical systems
• Compliance: Conforms to Mini ISO relay standards (ISO 7588-1); blade terminals per ISO 8092-1
• Environmental Compliance: Meets RoHS (2002/95/EC) and REACH directives
• OEM Part Number: 4RA 965 400-101

Common Applications:

• Engine control units
• Fuel pumps
• Fan motors
• Horns and fanfares
• Headlight cleaning systems
• General-purpose multi-function switching

Hella is a globally recognized OEM supplier producing over 100 million relays annually, with quality certifications including DIN EN ISO 9001, ISO/TS 16949, and ISO 14001. The 965400101 brings that same factory-level reliability to the independent aftermarket.
