Edelbrock 61595 RPM CNC Pontiac D-Port Cylinder Head 72cc Hydraulic Roller

Manufacturer

Part Number

61595
Black Friday Price

$1,775.95

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Edelbrock 61595 RPM CNC Pontiac Cylinder Head is engineered for serious performance builds on 1962-79 Pontiac V8 engines including 389, 400, 421, 428, and 455 cubic inch applications. Designed for engines with a 4.060" or larger bore, this complete cylinder head features a D-Port exhaust port configuration that works with standard D-port exhaust systems.

Key Features:

  • 72cc combustion chamber volume for optimized compression ratios
  • CNC-machined ports for maximum flow and performance
  • D-Port exhaust configuration for compatibility with factory-style exhaust manifolds
  • Relocated spark plug position closer to exhaust valve for improved combustion efficiency
  • Optimized oil return passages for increased oil flow and reduced cylinder pressure
  • Extra thick port walls and compact port size ideal for custom porting applications
  • Machined heat crossover passages for 50-state emissions compliance
  • Complete assembly includes guide plates, rocker studs, and premium valvetrain components

This cylinder head is designed for hydraulic roller camshaft applications and provides a direct bolt-on upgrade for Pontiac enthusiasts looking to maximize performance while maintaining street-friendly reliability. The CNC-machined ports deliver superior airflow compared to stock castings, while the relocated spark plug positioning improves flame propagation for more complete combustion.

Products specifications

Valve Angle

14

Valve Included

Yes

Exhaust Port Location

Standard

Camshaft Type

Hydraulic Roller

Valve Springs Included

Yes

Material

Aluminum

Push Rod Diameter

(Suggested) 0.3125

Deck Thickness

0.625

Seat Material

Ductile Iron

Construction Type

Complete

Guide Plates Included

Yes

CARB Executive Order Number

D-215-94

Horsepower

400-500

Quantity

Sold individually

Intake Valve Diameter

2.11

CNC Ported

Yes

Guide Material

Manganese Bronze

Seat Angle

Exhaust 45 deg/Intake 45

Combustion Chamber Volume

72

Intake Runner Volume

204

Exhaust Valve Diameter

1.66

Valve Stem Diameter

0.3438

Grade Type

Performance

Valve Spring Diameter

1.46

EGR Port

Yes

Valve Spring Maximum Lift

0.575

Family

Performer

Guide Plate Material

Hardened Steel

Series

Performer

Exhaust Runner Volume

145

RGL

WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.

Retainer Included

Yes

Rocker Stud Diameter

0.4375

Rocker Arm Stud Diameter

0.4375
