Edelbrock 75945 RPM Air-Gap EFI Intake Manifold for Holden V8 1988-98

Manufacturer

Part Number

75945
Black Friday Price

$699.95

In Stock (10+)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Edelbrock 75945 RPM Air-Gap EFI intake manifold is engineered for street and high-performance 308-383 cubic inch Holden V8 engines equipped with 1988-98 Holden VN cylinder heads. The signature Air-Gap design features an open air space that separates the intake runners from the heat of the lifter-valley cover, keeping the air/fuel mixture cooler all the way to the heads for a denser charge and increased power output.

Performance Features:

  • Dual-plane design tuned for excellent throttle response from 1,500 to 6,500 rpm
  • Dyno-proven performance: 426 ft-lbs of torque and 433 horsepower on a 355 cid test engine
  • Runners tuned to move the power band 1,000 rpm higher than standard Performer Air-Gap manifolds
  • Delivers excellent torque and horsepower gains on 308-383 cid applications

Technical Specifications:

  • Port exit dimensions: 1.16" x 2.00"
  • Throttle body pad height: 5.31"
  • Water crossover machined for standard Small-Block Chevy water neck
  • Satin aluminum finish

This manifold is designed to fit both stock 1988-1998 Holden EFI style cylinder heads and Edelbrock Holden VN RPM cylinder heads. Ideal for enthusiasts using late-style heads on early engine blocks or swapping late-model engines into early vehicles. Note: Does not suit VT models with factory roller camshaft.

Installation Notes: Do not use high-performance or competition-type intake gaskets for street applications; use stock gasket set or equivalent to prevent vacuum and oil leakage. Fuel rails required: Edelbrock #ED3504 (sold separately).

Products specifications

Single Or Dual Plane Type

Dual Plane

Front Maximum Height

4.800

Center Maximum Height

5.310

CNC Ported

No

Gasket Or Seal Included

No

Rear Maximum Height

5.820

RGL

WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.

Finish

Satin

Material

Aluminum

Grade Type

Performance

EGR Port

No

Single Or Dual Plane Type

Dual

Series

RPM Air-Gap

Basic Operating RPM Range

1500-6500

Vehicle Model

Holden

Flange Type

4150
