Edelbrock 7530 RPM Air-Gap Intake Manifold for AMC 290/343/390

(1968-1969 American Motors Javelin; 1968-1969 American Motors AMX; 1967-1969 American Motors Ambassador; 1967-1968 American Motors American + 3 more models)

Manufacturer

Part Number

7530
Black Friday Price

$545.95

Estimated ship date Wednesday, December 02

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Edelbrock 7530 RPM Air-Gap intake manifold is engineered for 1967-1969 AMC V8 engines with 290, 343, and 390 cubic inch displacements. This high-performance manifold incorporates proven race-winning technology derived from Edelbrock's Victor Series competition intakes, delivering measurable power gains through innovative thermal management.

Air-Gap Design Technology:

The defining feature of this manifold is its air-gap design, which creates an open air space between the intake runners and the engine valley. This separation prevents heat transfer from hot engine oil to the incoming air charge, resulting in cooler, denser air for improved combustion efficiency and increased horsepower.

Key Features:

  • Designed specifically for AMC 290, 343, and 390 cubic inch V8 engines (1967-1969)
  • Air-gap design isolates runners from engine heat for maximum power
  • Square-bore carburetor flange configuration
  • Standard oil fill and PCV valve provisions included
  • Early air conditioning support bracket accessory bosses
  • No exhaust crossover for reduced heat retention
  • No provision for exhaust-heated chokes

This manifold is ideal for street/strip applications where maximum performance is desired. The elimination of exhaust heat crossover passages ensures the intake charge remains as cool as possible, though a manual or electric choke will be required for cold-start operation.

Products specifications

Fits

1968-1969 American Motors Javelin; 1968-1969 American Motors AMX; 1967-1969 American Motors Ambassador; 1967-1968 American Motors American; 1967-1969 American Motors Rebel; 1969 American Motors Rambler; 1967 American Motors Marlin

Material

Aluminum

Front Maximum Height

4.450

Rear Maximum Height

5.770

Gasket Or Seal Included

No

Center Maximum Height

5.110

CNC Ported

No

RGL

WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.

Single Or Dual Plane Type

Dual Plane

Grade Type

Performance

Finish

Satin

Vehicle Model

AMC/Jeep

Flange Type

4150

Series

RPM Air-Gap

EGR Port

No - For 1967-69 290-390 c.i.d.

Single Or Dual Plane Type

Dual

Basic Operating RPM Range

1500-6500
