Edelbrock 61569 RPM CNC Pontiac D-Port Cylinder Head 87cc Bare

Manufacturer

Part Number

61569
Black Friday Price

$1,208.95

Estimated ship date Wednesday, December 02

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Edelbrock 61569 Performer RPM CNC Pontiac D-Port Cylinder Head delivers exceptional performance for classic Pontiac V8 engines. Engineered specifically for 1962-79 389, 400, 421, 428, and 455 cubic inch Pontiac engines with a 4.060" or larger bore, this bare cylinder head features an 87cc combustion chamber and a D-Port exhaust port configuration designed to work with standard D-port exhaust systems.

Key Features:

  • D-Port exhaust port configuration compatible with stock exhaust manifolds and headers
  • 87cc combustion chamber volume for optimized compression ratios
  • Relocated spark plug position closer to exhaust valve for improved combustion efficiency
  • Optimized oil return passages for increased oil flow and reduced oil retention
  • Extra thick port walls with compact port sizing ideal for CNC or hand porting modifications
  • Machined heat crossover passage for 50-state emissions compliance
  • Premium aluminum casting for weight savings and heat dissipation

This bare cylinder head is sold individually and requires separate purchase of valvetrain components, guide plates, and rocker studs for installation. The robust casting and port design make this head an excellent foundation for both street performance and racing applications, with plenty of material for custom porting work to match your specific combination.

Products specifications

Quantity

Sold individually

Valve Included

No

Series

Performer

Material

Aluminum

Construction Type

Bare

Valve Angle

14

Family

Performer

Grade Type

Performance

CARB Executive Order Number

D-215-94

Horsepower

400-500

Combustion Chamber Volume

87

Valve Springs Included

No

Guide Plates Included

Yes

Seat Material

Ductile Iron

EGR Port

Yes

CNC Ported

Yes

Retainer Included

No

Exhaust Port Location

Standard

Guide Material

Manganese Bronze

Intake Runner Volume

204

Guide Plate Material

Hardened Steel

RGL

WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.

Deck Thickness

0.625

Exhaust Runner Volume

145

Seat Angle

Exhaust 45 deg/Intake 45

Product Series

Performer

Product Family

Performer

9040

D-215-94
