Carrillo SC7471-6 Forged Piston Set 86mm 10.0:1 Toyota 2JZ

The Carrillo SC7471-6 is a high-performance forged piston set engineered specifically for Toyota 2JZ-GTE and 2JZ-GE engines.

Key Specifications:

• Bore: 86.0mm (3.389 inches) - Standard size
• Compression Ratio: 10.0:1
• Compression Height: 33.9852mm (1.339 inches)
• Pin Diameter: 22mm (0.866 inches)
• Stroke: 86mm
• Rod Length: 142mm (5.509 inches)
• Dish Volume: -4.5cc

Premium Features:

• High-strength aluminum forgings with dedicated forging dies
• Fully CNC machined for precision tolerances
• Precision balanced to +/- 1 gram for smooth operation
• Deep valve reliefs to accommodate high-lift camshafts and oversized valves
• Accumulator grooves and dual forced pin oilers
• Pick lock grooves for secure ring installation
• Wrist pins and pin fitting included at no additional cost
• Compatible replacement rings: CPN 3386
• Compatible wrist pins: 866-2250-15CP1C
• Made in USA

CP-Carrillo pistons are renowned for their exceptional quality and durability in high-performance and racing applications. Each piston undergoes extensive research and development to ensure maximum power output and reliability under extreme conditions. These pistons are trusted by professional racing teams worldwide for their ability to withstand the punishment of forced induction and high-RPM operation.
